DS2072 70MHz, 2 CH Digital Storage Oscilloscope

Product Description

Model	DS2072
Bandwidth	70 MHz
Analog Channels	2
Sample Rate	2 GSa/s
Max Memory Depth	14Mpts(standard) ,56Mpts(option)
Display	8 inch LCD display
Standard Interface	USB Host & Device, RS-232, P/F Out
Impedance	High Impedance and 50 Ohm matching

Features

• Wider vertical range(500uV/div ~ 10V/div), lower noise floor, better for small signal capturing
• Full bandwidth, lower overshoot(<5%), perfect frequency response design
• Bandwidth 70MHz,100MHz,200MHz
• Max. Sample Rate 2G Sa/s
• Standard Memory Depth up to14Mpts,Optional Memory Depth up to 56Mpts
• Innovative "UltraVision" technology
• 50 Ohm Impedance included

User Manual

For detailed performance parameters and technical specifications, refer to DS2000 Series Datasheet.
