DS6102 1GHz, 2 CH Digital Storage Oscilloscope

Product Description

Bandwidth	1 GHz
Analog Channels	2
Vertical Sensitivity	2 mV/div – 10V/div
Real-time Sample Rate	5 GSa/s（single channel mode），2.5 GSa/s（dual channel mode）
Memory Depth	140 Million Points
Waveform Acquisition Rate	180,000 Waveforms per Second
Standard Interface	USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution	8 bits
Math	＋, －, ×, FFT, customizable user defined
Cursor Measurements	Manual, Track and Auto Measure modes

5 GSa/sec max sample rate
140 Million Memory Points Standard
180,000 Waveforms per Second Acquisition
180,000 Frames Recording Capability
Trigger modes: edge, pulse width, slope, video, RS-232, I2C, SPI, and CAN (serial data trigger modes are standard, but on-board decoding requires the related options)

For detailed performance parameters and technical specifications, refer to DS6000 Series Datasheet
