5238 Automatic Transformer Tester

Call For Price

Category: .

Product Description

Description:

Automatic transformer test system
5238 Series Transformer Analyzers are high performance, fully automatic test system which integrates a precision inductance analyzer with a switch matrix. This total test solution will help to reduce cost, increase productivity, improve your delivery times and your product’s quality. 20Pins / 40Pins Fixture are available.

Incredibly simple and excellently accurate
The system provides a special open / short trim technology which can correct the fixture interference automatically. It can improve the system accuracy up to instrument level. The powerful functions and fixture design permitsrapid, accurate measurement of varioustransformer parameters in one test pass without the need to manually re-configure test connections. The operator needs only to follow a simple PASS/FAIL indicator to distinguish the DUT is good or not.

Increase production and quality – Cost saving
5238 Series Transformer Analyzers are designed for manufacturers who produce chokes and transformers of various types in small, medium and large batches. Specially designed for the production, it can provide comprehensive testing using non-skilled labor. It will reduce costs and dramatically increase throughput, permitting 100% testing. This will eliminate customer return, enhancing yoursupplierstatus.

Features:

  • 0.1% Basic Accuracy
  • Up to 200K Hz Frequency
  • Easily Programmed, De-skills Testing, Reduces Labor Costs
  • Speedy, Increases Productivity
  • Operator Just Loads & Removes Transformers
  • Precise Accurate & Reliable Results
  • Online Statistic, RS-232
  • Secure, Tamper-proof Programs

Specifications:

Model 5238
Test Parameter
Transformer Scanning Turn Ratio, Phase, L, Q, Leakage L, Balance, ACR, Cp, D, X, Y, DCR, Pin Short
Test Signals Information
Test Frequency (0.01%, 5digits) Turn 50Hz ~ 200KHz (10Vac Max.)
Others 20Hz~200KHz (2Vac Max.)
Output Impedance 100Ω
Display Range
L, LK 0.00001uH~9999.99H
C 0.00001pF~999.99mF
Q, D 0.00001~99999
Z, X, R 0.00001Ω~99.9999MΩ
Y 0.01nS~99.9999S
θ -90.00o~+90.00o
DCR 0.01mΩ~99.999MΩ
Turn 0.01~99999.99turns
Pin-Short 12 pairs, between pin to pin
Basic Accuracy
L, LK, C, Z, X, Y, R, DCR 0.1% (1kHz if AC parameter)
Q, D 0.0005 (1kHz)
θ 0.03o (1kHz)
Turn 0.5% (1kHz)
Measurement Speed (Fastest)
L, LK, C, Z, X, Y, R, Q, D, θ 75ms
DCR 25ms
Turn 75ms
General
Transformer Scanning PASS/FAIL judge of all test parameters output from optional HANDLER interface
Test Channel 20 Channels
Trigger Auto, Manual, External
Display 320*240 dot-matrix LCD display
Equivalent Circuit Mode Series, Parallel
Correction Function Open/Short Zeroing, Load deviation
Memory 64 instrument setups
Operation Environment Temperature :10oC ~ 40oC, Humidity :10%~90% RH
Power Consumption 140VA max.
Power Requirement 90Vac~125Vac or 190Vac~250Vac, 48Hz~62Hz
Weight Approx. 9kgs
Dimension (W*H*D) 360*150*420mm
Interface RS-232, Handler (option), USB (option)
